 Atess HPS 50-150KW US Version
Hybrid Solar Inverter
Atess inverter
three phase 220V hybrid inverter
US Version inverter 100KW

Atess HPS 50-150KW US Version

Large capacity all-in-one hybrid inverter for commercial
application, supporting up to 600kW system capacity

All-in-one hybrid inverter
Programmable working mode
Touchscreen LCD Quadruple capacity by paralleling 4 units
Supports remote control of DG
Seamless on/off grid transfer

  • رقم الصنف :

    Atess HPS 50-150KW US Version

  • النظام (موك) :

    Negotiable

  • قسط :

    T/T, etc

  • أصل المنتج :

    China

  • لون :

    White

  • ميناء الشحن :

    Shanghai, Ningbo, Shenzhen

  • مهلة :

    5-15 Days

  • وزن :

    According to model power
مطلوب الان
فئات المنتج
منتجات جديدة

Atess HPS 50-150KW US Version

Atess HPS inverter

Inverter Parameters

Model
HPS50-US
HPS100-US
HPS150-U
Apparent power
55kVA
110kVA
165kVA
Rated power
 50KW 100KW 150KW
Rated voltage
 190V 200V 208V 220V 240V  190V 200V 208V 220V 240V  190V 200V 208V 220V 240V
Rated current
152A 144A 139A 131A 120A
304A 289A 278A 262A  241A
456A  433A 416A 394A 361A
Voltage range
171-209V 180-220V 187-229V 198-242V 216-264V
171-209V 180-220V 187-229V 198-242V 216-264V
171-209V 180-220V 187-229V 198-242V 216-264V
Rated frequency
50/60Hz
Frequency range
45~55/55~65Hz
THD
<3%
Overload capability
110%-10 mins
120%-1 min
110%-10 mins
120%-1 min
110%-10 mins
120%-1 min
Max. PV open-circuit voltage
1000V DC
Max. PV power
75kWp
150kWp
225kWp
PV MPPT voltage range
480V-800V DC
480V-800V DC
Battery voltage range
352-600V
Max. charge current
150A
300A
450A
Max. discharge current
 156A 313A 467A
Dimension (W/H/D)
950/1860/750mm
1200/1900/800mm
1200/1900/800mm
Weight
610kg
948kg
1230kg
Display
Touch screen
Communication
RS485/CAN


AC coupling solution for medium size C&I

Medium-size AC coupling solution that can work for self-consumption, load-shifting, and backup power, providing reliable battery storage for renewable energy.



Hybrid solar inverter

Application Scenarios

● Schools: Medium energy storage systems support daily teaching equipment operation, emergency lighting, and reduces reliance on grid power during peak hours.



● Business districts: Commercial solar battery storage systems power retail stores, office buildings, and public facilities, stabilizing energy supply and cutting operational costs.



● Hospitals: Ensures uninterrupted power for medical devices, emergency rooms, and critical infrastructure, safeguarding patient safety.



Products Display

HPS 50-US

Exhibition

battery exhibition



Why Choose Greensun

1.We are a real factory and have strict requirements on the quality of products.



2.We provide OEM services for many leading companies around the world. we also have long-term cooperation with Solis, Deye,Growatt, Must,SMA and other tier-one brands.



3.As a factory, we have better control over product costs.



4.Both production and delivery are very fast.



5. Also, we provide stable and long-term after-sales service.





If you have any Solar needs,

You can write to us below⬇️⬇️⬇️，and contact us directly.

We will tailor a specific energy storage product to meet your specific needs.



العلامات الساخنة :

Atess inverter

three phase 220v inverter

HPS100-US

Hybrid solar inverter

Atess PCS

HPS150-US
